Key Features

ARCLED7507QZOOM is a new generation ParLED zoom, designed for rental-company, with a multi-purpose concept suitable for both stage and architectural lighting, in environments of large and medium size, both indoors and outdoors. ARCLED7507QZOOM offers unprecedented performance, employing Osram Ostar LED 7x15W RGBW/FullColor and a highefficiency 8°-40° optical zoom system for applications such as washer, beamer or both in the same stage-plot. The color calibration system, 2800K-10000K built-in white preset, 5 selectable dimmer curves and the total absence of fans, makes ARCLED7507QZOOM suitable for light design with high demanding requirements.

Light source and optics

• 7 x 15W Osram Ostar RGBW/FullColor LEDs
• Lumen: 1500lm
• Lux: 12590@2m
• Energy-saving LEDs employed, with more vivid colours and lower power consumption than traditional lamps
• Colour synthesis: RGBW Fullcolour mixing (>16 million colours) for a limitless colour range
• White temperature presets: 2800K~10000K
• Beam angle: 8°-40° Zoom
• Field angle: 11°-43°Zoom
• Electronic linear zoom with motorized and scrolling lens panel
• LEDs average life span: >50’000h
 Electronics and features

• LED display control panel
• Several DMX configurations selectable (3, 4, 5, 6, 7, 12, 17, 25 channels) for advanced or basic controlling
3 channels: RGB
3 channels: HSV
4 channels: RGBW
4 channels: Dimmer, RGB
5 channels: Dimmer, RGBW
6 channels: Dimmer, RGBW, strobo
7 channels: Dimmer, RGBW, zoom, zoom reset zoom, zoom reset
12 channels: Dimmer, RGBW, macro, strobo, auto, auto speed, dimmer curve, zoom, zoom reset
17 channels: Dimmer, dimmer fine, RGBW, RGBW fine, macro, strobe, auto, auto speed, dimmer curve, zoom, zoom reset
25 channels: Dimmer, dimmer fine, RGBW1, RGBW1 fine, RGBW2, RGBW2 fine, macro, strobe, auto, auto speed, dimmer curve, zoom, zoom reset
• Half-ring controllable
• LED display user interface for auto programs execution, static colour mode, creation of custom shows, colour calibration presets
• 5 different dimming available curves
• Master/Slave mode for stand-alone operations
• Linear and “step less” transition between DMX values
• Flicker-free operations (400Hz)
• Silent operations, due to natural convection cooling of the peculiar chassis and to absence of fans
Structure and Power supply

• Sturdy die-cast aluminium body conceived for long-time durability and demanding applications
• Frontal tempered glass panel
• Internal Protection: IP67 (IP) - IP54 (TZ)
• Pressure and temperature balance through GORE membrane vents
• Power (shuko) and data (xlr-3p) adapter cables included
• Double hanging bracket suitable for safe hanging and for floor positioning
• Power unit: 100-240V 50/60Hz
• Working temperatures: -40/45°
• Power output to link more units in a chain: up to 24 fixtures at 230V
• Max power consumption: 105W
• Weight: 7 kg
• Dimensions (WxHxD): 190x324x228 mm
